As a core industrial device for material storage and conveying, the Ash Discharge Valve discharges dust, particles and other solids quantitatively and continuously under sealed conditions. It isolates internal and external air pressure to prevent leakage and secondary dust emission, and maintains stable pressure in dust removal and pneumatic conveying systems.
| Quantity: | |
|---|---|
The Sealed Ash Discharge Valve is a core component for pneumatic conveying systems, developed by Botou Xintian Environmental Protection Equipment Co., Ltd.—a leader in industrial environmental solutions with ISO9001 certification. This Pneumatic Conveying Ash Valve features ultra-high sealing performance, solving the common problems of ash leakage and air leakage in traditional valves. It is engineered for continuous and stable operation in harsh industrial environments, efficiently discharging ash, powder, and granular materials while maintaining system pressure balance. As a trusted Industrial Air-Tight Ash Discharge Valve, it serves B-end customers in power plants, cement factories, and metallurgical industries, delivering reliable performance and reducing operational costs.
The valve adopts a double-sealing design (metal-to-metal primary seal + wear-resistant rubber secondary seal) to achieve air tightness ≤0.02 MPa. The valve plate is precision-machined via robot welding technology, ensuring tight fit with the valve body and preventing ash leakage even under high-pressure conditions. This design reduces energy loss by 15% compared to conventional valves.
The internal flow channel is optimized with a streamlined structure, reducing material adhesion and accumulation. The valve’s impeller is made of wear-resistant alloy steel (subjected to nitriding oxidation treatment), enhancing its wear resistance and preventing jamming caused by hard particles. It supports continuous operation for 24 hours without manual intervention.
The valve body is coated with anti-corrosion paint, while key components are treated with nitriding oxidation to resist corrosion from acidic and alkaline ash. This ensures stable performance in harsh environments (temperature range: -20℃ to 200℃), extending the service life to 5-8 years.
Adopting a modular design, the High-Seal Pneumatic Conveying Discharge Equipment can be quickly installed and connected to existing pneumatic conveying systems. The detachable valve cover and replaceable seal rings simplify maintenance, reducing downtime and labor costs for customers.
Parameter | Specification |
Model | XTSV-D28/XTSV-D16 |
Nominal Diameter (DN) | 80-400 mm |
Working Pressure | -0.08 MPa to 0.6 MPa |
Temperature Resistance | -20℃ to 200℃ |
Material | Valve body: Carbon steel/Q235; Seal: Wear-resistant rubber; Impeller: Alloy steel |
Flow Rate | 5-50 m³/h |
Drive Mode | Electric (0.75-5.5 kW) / Pneumatic |
Rotational Speed | 10-60 r/min |
Installation Type | Horizontal / Vertical |
Widely used in boiler ash discharge of thermal power plants, it efficiently handles fly ash and bottom ash, ensuring stable operation of dust removal systems and complying with environmental protection standards.
Suitable for discharging cement clinker, limestone powder, and gypsum powder in cement factories. Its high sealing performance prevents material leakage and maintains workshop cleanliness.
Applied in steel mills and non-ferrous metal smelters for discharging blast furnace dust and smelting slag. The corrosion-resistant design adapts to high-temperature and corrosive working conditions.
Ideal for conveying and discharging chemical powders (e.g., ammonium sulfate, phosphate fertilizer). The anti-jamming feature ensures continuous production of chemical production lines.
To meet the diverse needs of B-end customers, we provide personalized customization:
Diameter Customization: Nominal diameter can be tailored from 80 mm to 400 mm based on system flow requirements.
Seal Material Customization: Optional fluorine rubber or PTFE seals for special media (e.g., strong acid/alkali).
Temperature & Pressure Customization: High-temperature (up to 300℃) or high-pressure (up to 1.0 MPa) versions available for extreme environments.
Drive Mode Customization: Electric (variable frequency adjustable) or pneumatic drive options to match customer’s power supply conditions.
Our company is equipped with domestic leading processing equipment and robot welding workstations, ensuring the precision and consistency of each valve component. The strict quality inspection process (including pressure testing and sealing testing) guarantees product reliability.
Our professional R&D team provides one-stop solutions, including on-site inspection, program design, and equipment customization, to perfectly match customers’ pneumatic conveying systems and improve overall operational efficiency.
Each Sealed Ash Discharge Valve undergoes rigorous performance testing, including 72-hour continuous operation testing, sealing testing, and corrosion resistance testing, ensuring it meets industrial standards and customer requirements.
We offer 24/7 technical support via phone, email, and WhatsApp. Our after-sales team provides on-site installation guidance and maintenance services, with spare parts available for quick delivery to minimize customer downtime.
