Unlike fixed dust collection systems, this mobile woodworking dust extractor combines powerful suction, compact design, and easy maneuverability to address dust pollution in dynamic work environments such as on-site construction, small workshops, and multi-location processing. Compliant with international environmental standards and manufactured under our ISO9001-certified quality system, it efficiently captures wood dust, chips, and debris from portable woodworking tools, ensuring a clean and safe operation while maintaining production flexibility for small to medium-sized enterprises.
Constructed with high-strength, lightweight steel materials and equipped with heavy-duty rubber wheels with brakes, the dust collector weighs only 50-80 kg, allowing a single worker to move it effortlessly between workstations. The compact size (≤1200×600×1500 mm) enables easy storage in narrow spaces, while the telescopic push handle and balanced center of gravity ensure comfortable operation without fatigue.
Featuring a plug-and-play design, the dust collector can be set up and operational within 5 minutes—no complex installation or professional technical support required. The intuitive control panel with clear indicators allows workers to adjust suction power, activate cleaning functions, and monitor filter status with minimal training. Additionally, the quick-release dust bucket simplifies emptying and maintenance, improving work efficiency.
Equipped with a high-performance vortex motor, the dust collector delivers strong suction (180-250 mbar) to capture dust from various wood processing tasks, including sanding, drilling, and trimming. The dual-stage filtration system (cyclone separator + fine filter) effectively separates large chips and fine dust, with a filtration efficiency of 99.8% for particles ≥0.5μm. This targeted filtration prevents dust accumulation on tools and workpieces, ensuring processing precision.
Parameter | Specification |
Model | XTS-PD180 / XTS-PD250 |
Air Volume | 800-1500 m³/h |
Filter Efficiency | ≥99.8% (for particles ≥0.5μm) |
Rated Power | 2.2-4 kW |
Dust Bucket Capacity | 30-60 L |
Voltage | 220V/50Hz (customizable for 110V/60Hz) |
Overall Dimensions (L×W×H) | 900×550×1300 mm / 1100×600×1500 mm |
Noise Level | ≤70 dB(A) |
Mobility | 4 rubber wheels (2 with brakes) |
Suction Pressure | 180-250 mbar |
Weight | 50-80 kg |
Hose Length (Standard) | 5 m (extendable up to 10 m) |
Ideal for construction sites, interior decoration, and on-site furniture installation. The portable design allows workers to move the dust collector directly to the work area, capturing dust from cutting and fitting wood components without polluting the surrounding environment.
Perfect for family workshops, craft studios, and small enterprises with limited space. The compact size and low noise level make it suitable for indoor use, while the efficient filtration ensures compliance with local environmental regulations and protects workers’ health.
Suitable for service providers offering on-site wood cutting, trimming, and customization. The dust collector’s portability and quick setup enable clean operation at client locations, enhancing professional image and customer satisfaction.
We understand the diverse needs of users in mobile dust removal, offering tailored customization options:
Portability Optimization: Customize wheel types (e.g., pneumatic wheels for rough terrain) or add lifting lugs for easy transportation.
Performance Adjustment: Modify air volume, suction pressure, and hose length to match specific processing tools (e.g., portable sanders, chain saws).
Battery-Powered Option: Provide rechargeable lithium-ion battery models for areas without power supply, supporting 4-8 hours of continuous operation.
Specialized Filters: Offer anti-moisture filters for humid environments or anti-static filters for processing flammable wood species.
Please inform us of your typical work scenarios, tool types, and power supply conditions to receive a personalized solution.
With years of experience in serving industrial users, we focus on practical needs and offer flexible customization to adapt to different application scenarios. Our engineering team works closely with clients to optimize product design, ensuring maximum compatibility with existing workflows.
Manufactured using the same precision processing equipment and quality control standards as our industrial-grade products, the portable dust collector features a sturdy structure and wear-resistant components. The ISO9001 certification guarantees consistent quality, while the annealing-treated steel frame resists deformation and extends service life.
Tailored for small to medium-sized users, our portable dust collector offers high performance at a competitive price point. It eliminates the need for expensive fixed piping systems, reducing initial investment and installation costs. The energy-saving motor and long-lasting filters also lower operating expenses over time.
We provide comprehensive pre-sales and after-sales support, including product demonstrations, technical consultations, and spare parts supply. Our global service network ensures timely response to inquiries via phone, WhatsApp, and email, while on-site service is available in key regions. We also offer a 1-year warranty and lifelong maintenance guidance to ensure long-term reliable operation.
