Welding, Grinding, Cutting
Processing stainless steel, carbon steel and other metals, welding produces high-temperature metal fumes (containing heavy metal particles such as iron oxide, manganese and chromium) with particle sizes mostly ranging from 0.1 to 10μm; grinding/cutting produces a large amount of metal debris and dust with concentrations up to 500-2000mg/m³, some processes are intermittent, and dust emissions fluctuate greatly; the operating environment is mostly scattered workstations in workshops with complex spatial layouts.
Inhalation of heavy metal dust can cause occupational diseases such as pneumoconiosis and manganese poisoning, resulting in irreversible damage to the respiratory and nervous systems of workers;
Metal dust is combustible dust, and accumulation can easily cause dust explosions when exposed to ignition sources (such as aluminum powder and magnesium powder processing);
Untreated dust emissions exceeding standards violate the "Integrated Emission Standard of Air Pollutants" (GB 16297-1996), facing risks of fines and production suspension for rectification;
Dust adhering to the surface of production equipment can easily lead to equipment wear, reduced precision and increased maintenance costs.
Decentralized + Centralized Combined Dust Removal Solution
For decentralized workstations (such as welding and small-scale grinding), mobile welding fume purifiers are used for point-to-point purification; for centralized production lines (such as large-scale grinding workshops), central dust collection systems are used to collect dust from each workstation to the main unit for purification through pipelines.
Select high-negative pressure and low-noise models, equipped with HEPA high-efficiency filter cartridges (filtration precision ≥0.3μm, filtration efficiency ≥99.97%) to adsorb heavy metal fine particles;
The main unit selects pulse bag filters, the filter bag material selects high-temperature resistant and wear-resistant P84 filter materials, and is equipped with spark detection and extinguishing devices to prevent metal sparks from igniting the filter bags;
Closed dust hoods are set at grinding workstations to improve dust collection efficiency.
Priority is given to HEPA high-efficiency filters to ensure that heavy metal fine particles meet purification standards, with filtration efficiency ≥99.97%;
Determine the air volume according to the number of workstations and dust emissions. The air volume for a single welding workstation is recommended to be ≥1200m³/h, and the air volume for centralized production lines is equipped with 1.2 times the total emissions;
For combustible metal dust, explosion-proof equipment must be selected, equipped with spark detection and extinguishing devices;
For decentralized workstations, mobile equipment is preferred for flexible adjustment and space saving.
We have been deeply engaged in the dust removal equipment industry for 15 years, focusing on customized solutions for various industries. With the core advantages of "leading technology, reliable products and comprehensive services", we have become the preferred partner of many enterprises:
We have a professional industry research and technical team, deeply understanding the production processes and dust characteristics of various industries. We have successfully provided customized solutions for more than 20 industries including metal processing, building materials, chemicals, wood processing, spray painting industry, mining and electronics, serving more than 5000 customers cumulatively. With rich case experience, we can accurately match the needs of different working conditions.
Possessing a number of patented technologies for dust removal equipment, independently developed high-efficiency filter materials, intelligent pulse cleaning systems and explosion-proof monitoring systems, with industry-leading purification efficiency and safety performance;
Adopting the ISO9001 quality management system, the core components of the equipment (filter materials, fans, pulse valves) are all selected from well-known brands, and have undergone strict testing to ensure stable operation of the products;
All solutions comply with the latest national environmental protection standards, and can assist enterprises in passing environmental protection acceptance.
We provide full-cycle services from "working condition research - solution design - equipment production - installation and commissioning - post-maintenance". We can flexibly adjust the solution according to the enterprise's production scale, site constraints and budget requirements to achieve "customization on demand and optimal cost performance".
For flammable, explosive, toxic and harmful dust, complete explosion-proof, poison-proof and monitoring devices are equipped, and all safety equipment has passed authoritative certification; strict risk assessment is carried out during the solution design process to ensure safe operation of equipment and reduce enterprise production risks.
We have set up more than 20 service outlets nationwide, with a professional installation and after-sales team, providing 24-hour emergency response services; free maintenance and replacement of accessories are provided during the equipment warranty period, and lifelong maintenance services are provided after the warranty period. Regular on-site inspections are carried out to ensure long-term stable operation of the equipment.
Focusing on customer needs, we provide full-process and one-stop services covering the entire life cycle of dust removal projects:
Professional technical personnel conduct on-site visits to deeply understand the enterprise's production process, dust generation links, concentration, particle size, physical and chemical properties, as well as environmental protection requirements, site constraints, budget and other information, and issue detailed working condition research reports.
Based on the results of working condition research, a team of senior engineers designs customized dust removal solutions, including equipment selection, pipeline layout, air volume calculation, safety protection design, etc., and issues detailed solution specifications and quotations to provide customers with clear project planning.
Production is organized according to the solution requirements, core components are selected from high-quality materials, and the production process strictly follows the quality management system; after the equipment production is completed, a number of performance tests (purification efficiency, air volume, noise, explosion-proof performance, etc.) are carried out to ensure that the products meet the solution requirements and industry standards.
A professional installation team provides on-site services, strictly carrying out equipment installation, pipeline laying and electrical connection according to the construction plan; after the installation is completed, comprehensive commissioning is carried out to optimize the equipment operation parameters to ensure that the purification effect meets the standards and the equipment operates stably.
Provide professional training for enterprise operators, including equipment working principles, operating procedures, daily maintenance, safety precautions, etc., to ensure that operators can proficiently master equipment use and maintenance skills.
The equipment warranty period is 1-3 years (depending on the equipment type). During the warranty period, free maintenance and replacement of non-human-damaged accessories are provided;
24-hour after-sales hotline, after receiving a fault notification, technical personnel from nearby service outlets will arrive at the scene for processing within 2-8 hours;
On-site inspections are carried out every 3-6 months during the warranty period, and at least 2 inspections are carried out every year after the warranty period to check the equipment operation status, clean up accumulated dust, replace worn accessories and provide maintenance suggestions;
Provide lifelong maintenance services for equipment, and reasonable fees for accessories and services are charged after the warranty period.
Assist enterprises in preparing materials required for environmental protection acceptance (solution specifications, test reports, equipment qualifications, etc.), and cooperate with environmental protection departments to conduct on-site acceptance to ensure the smooth passing of the project's environmental protection acceptance.
Answer: It can be judged in two ways: ① Third-party testing: Entrust a qualified environmental protection testing agency to test the dust concentration at the equipment outlet to ensure compliance with relevant standards such as the "Integrated Emission Standard of Air Pollutants" (GB 16297-1996); ② Equipment monitoring: Select equipment equipped with dust concentration monitors to view the real-time dust concentration data at the outlet and intuitively judge the purification effect.
Answer: The maintenance cost of dust removal equipment is relatively low, mainly including three parts: ① Accessory replacement: Filter materials (filter bags, filter cartridges) are the main wearing parts. The replacement cycle depends on the working conditions (generally 3-12 months). The replacement cost of high-quality filter materials accounts for about 5%-10% of the total equipment price; ② Energy consumption cost: The fan operates with electricity. Our equipment adopts high-efficiency and energy-saving fans, and the energy consumption is 15%-20% lower than the industry average; ③ Labor cost: Daily cleaning of accumulated dust and equipment inspection are simple operations that do not require special personnel on duty, resulting in low labor costs.
Answer: We ensure safety through "triple protection": ① Equipment explosion protection: Select motors, fans and electrical components with explosion-proof grades meeting industry standards, and the equipment shell adopts an explosion-proof design; ② Explosion suppression: Equipped with explosion vents, flame arresters and explosion suppression devices. Explosion vents can release pressure in an instant during an explosion, flame arresters prevent the spread of explosion flames, and explosion suppression devices can quickly extinguish explosion flames; ③ Monitoring and early warning: Equipped with dust concentration, temperature and pressure monitors to monitor the equipment operation status in real time. When parameters are abnormal, it automatically warns and shuts down to avoid danger.
Answer: The installation cycle depends on the project scale. Small-scale decentralized equipment (such as mobile welding fume purifiers) is simple to install and can be completed in 1-2 days; the installation cycle of large-scale central dust collection systems is about 7-30 days. We will communicate with customers in advance to formulate a reasonable installation plan, and try to choose production gaps and holidays for installation to reduce the impact on normal production; for large-scale projects, phased installation and commissioning can be adopted to ensure the normal operation of some production lines.
Answer: Universal use is not recommended. The dust working conditions (concentration, particle size, physical and chemical properties) of different industries are quite different. For example, heavy metal dust in metal processing, flammable and explosive dust in the chemical industry, and ultra-fine dust in the electronics industry have completely different requirements for equipment filtration precision, explosion-proof performance and material. Universal equipment cannot accurately adapt to working conditions, which may lead to substandard purification effects, equipment damage and even safety accidents. We recommend customizing exclusive equipment according to the specific industry working conditions.
Answer: If a fault occurs in the equipment, it can be handled in the following steps: ① Emergency shutdown: In case of serious faults (such as abnormal noise, peculiar smell, dust leakage), immediately cut off the equipment power supply to avoid expanding the fault; ② Contact after-sales service: Call our 24-hour after-sales hotline to explain the fault phenomenon, equipment model, working conditions and other information; ③ On-site processing: Technical personnel from nearby service outlets will arrive at the scene within 2-8 hours to troubleshoot and repair; ④ Emergency support: For key production links, we can provide temporary backup equipment to ensure uninterrupted production.
