Introducing the Automatic Cartridge Dust Collector, an intelligent automatic plant dust collection system developed by Botou Xintian Environmental Protection Equipment Co., Ltd. for large-scale industrial plants and automated production lines. Integrating robot automation integration technology and intelligent control systems, this equipment achieves unmanned operation, efficient dust removal, and intelligent monitoring, setting a new standard for modern industrial air purification.
| Quantity: | |
|---|---|
As a smart cartridge dust removal for industrial plants, it features automatic ash cleaning, pressure difference monitoring, and fault alarm functions, significantly reducing manual intervention and operational costs. The robust structure, manufactured using nitriding oxidation treatment and precision welding technology, ensures reliable operation in high-volume, continuous production environments. Our 4000㎡ production base and ISO9001 management system guarantee consistent product quality and on-time delivery.
The Automatic Cartridge Dust Collector adopts PLC control technology, enabling automatic start/stop, timed ash cleaning, and real-time pressure difference monitoring. When filter resistance reaches a preset value, the system initiates pulse jet ash cleaning automatically, ensuring stable filtration efficiency without manual operation—ideal for large plants requiring 24/7 operation.
Leveraging our expertise in robot welding workstation design solutions, the equipment is seamlessly compatible with automated production lines. It can be linked with production line control systems to achieve synchronized dust removal, adapting to the dynamic dust emission characteristics of intelligent manufacturing plants.
Key components such as the filter cartridge frame and shell undergo nitriding oxidation treatment, enhancing corrosion resistance and wear resistance. The filter cartridge adopts a pleated structure with large filtration area and long service life (2-3 years under normal conditions). The equipment’s base uses reinforced steel plates and shock-absorbing pads to ensure stability during high-speed operation.
The intelligent control system optimizes air volume based on real-time dust concentration, reducing energy consumption by 25% compared to traditional manual control equipment. The high-efficiency filter cartridge achieves ≥99.95% filtration efficiency, meeting strict environmental emission standards and helping enterprises achieve green production.
Item | Specification |
Filter Cartridge Material | High-efficiency polyester fiber + PTFE membrane |
Filtration Efficiency | ≥99.95% |
Air Volume Range | 2000-50000 m³/h |
Automatic Ash Cleaning Method | Pulse jet (solenoid valve control) |
Control System | PLC + touch screen (remote monitoring optional) |
Working Pressure | -800 to -1500 Pa |
Power Supply | 380V/50Hz, 3-phase |
Filter Cartridge Service Life | 24-36 months |
Intelligent Monitoring Functions | Pressure difference monitoring, fault alarm, ash cleaning status display |
Overall Dimension (L×W×H) | 2000×1200×2500 mm (base model) |
Weight | 600-1500 kg (depending on configuration) |
Suitable for automobile manufacturing, machinery assembly, and electronic component production plants. The automatic plant dust collection system efficiently handles large-area dust pollution, maintaining a clean environment across the entire workshop.
Ideal for intelligent production lines such as robot welding workstations and automated assembly lines. It synchronizes with production line operations to capture dust at the source, ensuring stable equipment performance and product quality.
Effectively captures dust from chemical raw material processing, plastic molding, and mechanical casting processes. The corrosion-resistant design and explosion-proof configuration (optional) adapt to special working conditions in chemical and machinery industries.
Targets dust generated during welding and machining of high-speed train air conditioning units, window assemblies, and other components (leveraging our experience in transportation equipment applications). It meets the high-purity production requirements of the rail transit industry.
Customers can customize intelligent functions such as remote monitoring, data analysis, and automatic fault diagnosis. The system can be integrated with the enterprise’s MES system to achieve unified management of production and environmental data.
Based on the layout and operation characteristics of automated production lines, we design customized dust collection points and ductwork routes. The equipment can be equipped with mobile or fixed dust collection hoods to adapt to different production processes.
For high-temperature, high-humidity, or corrosive dust environments, we provide customized filter materials and equipment structures (e.g., high-temperature resistant filter cartridges, stainless steel shells) to ensure stable operation under extreme conditions.
Intelligent Technology Advantage: Our engineering team specializes in robot automation integration and intelligent control systems, enabling us to provide advanced, reliable automatic dust removal solutions.
Strict Quality Control: As an ISO9001-certified enterprise, we implement full-process quality management, from component procurement to finished product testing, ensuring each Automatic Cartridge Dust Collector meets high-quality standards.
Rich Industry Experience: With successful applications in engineering machinery, transportation equipment, and food processing industries, we understand the unique dust removal needs of different sectors and provide targeted solutions.
Comprehensive After-Sales Support: We offer free equipment commissioning, operator training, and regular maintenance reminders. Our professional after-sales team provides on-site service within 48 hours for urgent issues, ensuring minimal production downtime.
Customization Capability: Leveraging our modular design expertise, we quickly respond to customer-specific requirements, delivering personalized equipment that perfectly matches their production needs and budget.
